LED Cabinet Specifications:

Pixel Pitch

4mm/5mm/6.67mm/8mm/10mm

Pixel Constitution

SMD 3IN1 1921/2525/2727/3535  LED

Module Size

320mm*160mm

Die Casting Aluminum LED Cabinet Size

640mm*960mm

LED Cabinet Resolution

160*240/ 128*192/96*144/80*120/64*96 dots

LED Cabinet Weight

16.5kg/cabinet

LED Display Parameters:

Brightness

5000-6500 cd/m2 (nits)

Optimum Viewing Angle

140°/140°

Power Supply Voltage

110V/220V Switchable

Gray Scale

≥16.7M colors(Synchronized)

Refresh Frequency

≥1920Hz

Frame Frequency

≥60-75Hz

Weather Protection

IP65 Waterproof

Operating Temperature

-20~50(-40~60optional)

Operating Humidity

10%-90%

Average No Falure Time

≥5000hours

Life Span

≥100,000hours

LED Control System

Linsn/Novastar/Colorlight/Huidu/Xixun etc

Warranty

3 Years Warranty

Certificates

CE,RoHs,FCC,UL,CCC
